FlexAnalog™ Development Boards

We offer an extensive range of FlexAnalog™ FPAA-based evaluation boards, development kits, add-on daughter cards and programming and debug hardware for effortless evaluation of the capabilities and features of all our FPAA family of devices and to enable quick prototyping of products and applications. We also provide easily accessible demonstration guides, application notes and sample designs to accelerate your time to market.  The following features are available for the FlexAnalog™ evaluation boards:

• Full integration with the Anadigm Designer2 software development platform
• Standard USB and PC serial interfaces for downloading Okika’s Anadigm Designer2 circuit configuration files
• Onboard non-volatile memory for configuration storage
• Microcontroller-based storage using Microchip PIC FLASH—enabling bootable circuit configurations
• EEPROM support with onboard socket (external EEPROM not included) for configuration storage and boot
• Compact board footprint
• Large breadboard area surrounding the FlexAnalog™ FPAA device
• Header pins for all analog I/Os of the FlexAnalog™ FPAA
• Electrically and physically separable digital section
• Dual circuit footprints for configurations like Rauch filters, single-to-differential converters, and level shifters
• Daisy-chain support for multi-board, multi-chip system evaluations
• Built-in oscillator module
